3-part system, sold separately: Rapid 2-in-1 Eaves Tray provides continuous ventilation over the fascia while supporting the underlay at the eaves to ensure a positive fall of the underlay into the eaves gutter Rafter Roll- a semi-rigid, roll-out rafter ventilation tray that maintains an uninterrupted air ventilation gap between the underlay and ceiling-level insulation in the loft space Eaves Comb- used to prevent birds, large insects, rodents etc. from entering the roof space. Eaves Comb is required for the following Redland tiles: Landmark Double Pantile, Grovebury, Regent, Fenland Pantile, Hollander Clay Pantile and Old Hollow Clay Pantile Maintenance-free Quick and easy to install Can be used with either a non-breather or vapour permeable underlay
Key Features
- Rafter pitch range is 15 - 70°
- The effective ventilation area per metre run of eaves is 10,000 mm2Works with any Redland slate / tile or similar
- Suitable for use with most pitched roofing materials
- Compatible with timber fascias up to 25 mm thick
- Suitable for uPVC fascias with an additional timber fillet behind the fascia board
- Suitable for rafter centres up to 600 mm
